High-temp Resistant Mini-pleat Filter

High-temp Resistant Mini-pleat Filter

Applications:

1) Clean room fresh air condition system, end filter of clean room air inlet.

2) Spray booth, car manufacturer over filtration system.

3) Widely used in electronics, optics, Semi-conductors painting, chemical, cosmetics, pharmacy, hospital, automobile industries etc.

Material:

1) Protective mesh: SS304 and Glass fiber mesh

2) Gasket: Glass Fiber

3) Separator: Mini-pleat glass fiber paper line

4) Filter material: Ultra-thin glass fiber paper

5) Outer frame material (Standard):  Galvanized steel frame

6) Outer frame material (Optional）: Stainless steel frame, Aluminum alloy frame

Features:

1) High-temp resistant up to 350℃.

2) large filtration area, high efficiency.

3) EN779:  G4~F9

4) EN1822: E11,E12, H13, H14

5) Special size available: Yes

6) Recommended Final Resistance: 500Pa
